Description

Steerable electric trackless transfer vehicle industrial tugger carts are used to move molds, coils or materials between the press room and the mold storage and maintenance area. The advantage of this kind of Steerable electric trackless transfer vehicle industrial tugger carts is that the entire length of the manufacturing facility can be moved, where the mold moved by the crane is limited by the travel distance of the crane, or must be transferred from the crane bracket to the crane bracket. Our standard heavy-duty design is controlled by a handheld button controller with a small turning radius.

APPLICATION:

The trackless tugger carts can be used for coil items, transformer, shaft, drum, steel ladle, steel structure, steel pipe, mold, beam, container, heavy equipment, aluminum product, compressor, polycrystalline silicon, motor, building materials, scrap, pallet and other material transport in the factory.

Mold		5T	10T	15T	20T	30T
Rated Load(T)		5	10	15	20	30
Table Size(mm)		2500*1500	3000*2000	3200*2000	4000*2000	5000*2200
Height(mm)		600	700	750	750	800
Wheel Quantity		4	6	8	8	12
On cement floor	Tire Specification	305*165	559*254	559*356	22*9-10	22*9-10
	Tire Material	Polyurethane Solid Wheel, Press-on Solid Tire, Air Tire
On rail	Rail Inner Gauge(mm)	1200	1435
	Wheel Material	LD steel wheel, Angel box wheel
Frame Material		Q235				Q345
Color		Customized
Speed(km/h)		0-20			0-15
